Start a project with Functional Products.
Functional Products Inc. manufactures lubricant additives, designs lubricant formulations, and validates performance throughout development to ensure consistency where it matters most.
Our approach to Build, Validate, and Scale your project is designed to reduce development risk, accelerate iteration, and support data-driven formulation decisions.
If you’re looking for a collaborator to help you achieve the big thing in your lubrication development, Contact Us.
Online Tools
Access our on-site tools for formulations, including the FUNCTIONAL LnGPT AI platform online here.
Laboratory Testing
Customers benefit from complimentary on-site laboratory testing and coordinated external analysis through a network of partner laboratories across North America.
Laboratory testing is performed to support formulation development, screening, and performance benchmarking. Functional Products Inc. is not an ISO/IEC 17025 accredited testing laboratory; data generated is intended for research and development use.
“Internal” methods are run on-site at Functional Products Inc. in Macedonia, Ohio. External testing is coordinated with off-site partner labs.
Test Name | Method | Test Type | Fluids | Grease | Internal |
|---|---|---|---|---|---|
pH by meter or strip | n/a | Acids/Bases | X | Yes |
|
Total Acid Number (TAN) | ASTM D974 | Acids/Bases | X | No |
|
Total Base Number (TBN) | ASTM D2986 | Acids/Bases | X | No |
|
Brookfield Viscosity using a Rotational Viscometer | ASTM D2983 | Cold Flow | X | Yes |
|
Pour Point - Manual Tilt Method (to -65C / -85F) | ASTM D97 | Cold Flow | X | Yes |
|
US Steel Mobility (0F/-10F/-20F/-30F) | n/a | Cold Flow | X | Yes |
|
Low Temperature Torque (for GC-LB) | ASTM D4693 | Cold Flow | X | No |
|
Low Temperature Torque (for HPM) | ASTM D1478 | Cold Flow | X | No |
|
Dielectric Strength - Flat Electrodes | ASTM D877 | Conductivity | X | Yes |
|
Dielectric Strength - Mushroom Electrodes | ASTM D1816 | Conductivity | X | Yes |
|
Dissipation Factor | ASTM D924 | Conductivity | X | No |
|
Electrical Conductivity of Fluids (0.001 – 500 µS/cm) by Probe | ASTM D1125 | Conductivity | X | Yes |
|
Turbine Oil Rust: A (Distilled Water), B (Salt Water) | ASTM D665 | Corrosion | X | No |
|
Corrosiveness and Oxidation Stability of Hydraulic Oils | ASTM D4636 mod | Corrosion | X | Yes |
|
Cast Iron Chip Corrosion | ASTM D4627 | Corrosion | X | Yes |
|
Copper Strip Corrosion - Fluids, 100C to 150C | ASTM D130 | Corrosion | X | Yes |
|
Copper Strip Corrosion - Grease, 100C to 150C | ASTM D4048 | Corrosion | X | Yes |
|
Density Cup - lbs/gallon | n/a | Density | X | X | Yes |
Specific Gravity @ 60F | ASTM D1298 | Density | X | Yes |
|
API Gravity | ASTM D1298 | Density | X | Yes |
|
Elemental Analysis by ICP-OES | ASTM D5185 | Elemental Analysis | X | No |
|
Elemental Analysis by XRF with Sulfur | ASTM D2622/D4294 | Elemental Analysis | X | No |
|
Biobased Carbon Analysis | ASTM D8282 | Environmental | X | X | No |
Biodegradability | OECD 301B | Environmental | X | X | No |
VOC Content | ASTM E1868 | Environmental | X | X | No |
Flashpoint - Cleveland Open Cup | ASTM D92 | Flammability | X | Yes |
|
Fire Point - Cleveland Open Cup | ASTM D92 | Flammability | X | Yes |
|
Foam Tendency and Stability - Seq I through IV | ASTM D892 | Foam | X | Yes |
|
Oxidation Characteristics of Extreme-Pressure Lubrication Oils | ASTM D2893 mod | Oxidation | X | Yes |
|
RPVOT Oxidation | ASTM D2722 | Oxidation | No |
||
G.M. Quenchometer Test | ASTM D3520 | Quench | X | No |
|
Cooling Curve using Quenchalyzer | ASTM D6200 | Quench | X | No |
|
20 Hour KRL | CEC L-45-A-99 | Shear Stability | X | Yes |
|
Worked Cone Penetration - 10K | ASTM D217 | Shear Stability | X | Yes |
|
Worked Cone Penetration - 100K | ASTM D217 | Shear Stability | X | Yes |
|
Roll Stability | ASTM D1831 | Shear Stability | X | No |
|
Falex Tackiness Adhesion Analyzer (TAA) | ASTM D8576 | Tackiness | X | Yes |
|
Ductless Siphon Tack Test (DS) | n/a | Tackiness | X | Yes |
|
FZG Gear Test | various | Tribotesting | X | No |
|
Vickers Vane Pump V104C | ASTM D2882 | Tribotesting | X | No |
|
Four-Ball Wear - Fluids | ASTM D4172 | Tribotesting | X | Yes |
|
Four-Ball Wear - Grease | ASTM D2266 | Tribotesting | X | Yes |
|
Four-Ball EP - WP, LNSL, LWI - Fluids | ASTM D2783 | Tribotesting | X | Yes |
|
Four-Ball EP - WP, LNSL, LWI - Grease | ASTM D2596 | Tribotesting | X | Yes |
|
Coefficient of Friction - Ramp Test | ASTM D5183 | Tribotesting | X | Yes |
|
Kinematic Viscosity @ 20C - 150C | ASTM D445 | Viscosity | X | Yes |
|
Viscosity Index | ASTM D2270 | Viscosity | X | Yes |
|
Dynamic Viscosity by Brookfield (-65C to 100C) | n/a | Viscosity | X | X | Yes |
Water Sprayoff (WSO) | ASTM D4049 | Water Resistance | X | Yes |
|
Water Sprayoff (WSO) | ASTM D4049 | Water Resistance | X | No |
|
Water Separability | ASTM D1401 | Water Resistance | X | Yes |
